Yaming’s LW5 16A Electric Manual Changeover Switch With Metal Shell Box stands out remarkably in terms of core performance and application scenarios. This series of changeover switches is suitable for circuit systems with AC 50Hz, rated voltage up to 500V and DC voltage up to 440V. It can be used to switch electrical control circuits such as electromagnetic coils, electrical measuring instruments and servo motors, and can also directly control 5.5kW three-phase squirrel-cage asynchronous motors to achieve operations like reversible conversion and speed regulation.
Details determine the stability and adaptability of industrial control. With many excellent features, LW5 16A Electric Manual Changeover Switch With Metal Shell Box becomes the ideal choice for industrial scenarios created by China factory.As a professional electrical switch manufacturer, we know the individual needs of different customers. This switch supports customized adjustment of gear and number of layers. At the same time, it is equipped with flexible external connection boards to adapt to various wiring schemes. The supplier direct supply mode can guarantee the product cost performance and delivery efficiency, providing efficient and adaptive control solutions for global customers.
Safety is at the heart of industrial electrical equipment, and this 16A Electric Manual Changeover Switch With Metal Shell Box is fully enhanced.China manufacturer strictly selects high-quality insulation materials to ensure excellent insulation performance from the source and minimize electrical safety hazards; the switching process is smooth and smooth without jamming, and the operation feels smooth, further improving the safety and reliability during use.As a strength factory, we insist on strict quality control standards for the production of each product, for the stable operation of industrial production to build a strong safety line.
The 16A Electric Manual Changeover Switch With Metal Shell Box not only performs well in performance, but also combines practicality and aesthetics in appearance design.Its fashionable and modern appearance can be perfectly integrated with the design style of various industrial equipment, which is not abrupt and more coordinated; rich function configuration can cover the control requirements of various industrial scenes, whether it is conventional electric manual switching or special control logic realization, it can be accurately competent.As a professional electrical switch supplier, we are committed to providing customers with high cost performance and high quality products, which are the best choice for both strength and beauty in the field of industrial control.
Classification by Application
Master control application
Direct control application for 5.5kW three-phase squirrel-cage asynchronous motors
Classification by Operation Mode: Self-locking type/Self-resetting type
Classification by Actuator Shape:Knob type/Ball grip type
Classification by Combination of Operation Mode and Actuator Position
